Knotty woodgrain Series steel sheet For soffit, fascia, metal cladding, metal walls, grooves
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Material: | Galvalume Steel, Galvanized Steel | Color: | Steel Woodgrain Series For Siding |
|---|---|---|---|
| Grade: | SGCC, SGCC,DX51D,ASTM A653,EN10142 | Standard: | AISI, ASTM, BS, DIN, GB, JIS |
| Paint: | PE, PVDF, SMP, HDP | Coil Weight: | 3-7 Tons |
| Application: | Siding & Architectural Accents | Zinc Coating: | 30-275gsm |
| Coil ID: | 508mm/610mm | Type: | Steel Coil |
| Special Use: | Wear Resistant Steel | Delivery Port: | Tianjin Or Qingdao |
Knotty woodgrain Series steel sheet For soffit, fascia, metal cladding, metal walls, grooves
Woodgrain Metal Series provides the character and beauty of wood with the durability, longevity and low maintenance of steel. Unlike its wood and wood veneer counterparts, our Woodgrain Metal was designed to stand the test of time. The base metal for our Woodgrain Series is a 55% Aluminum-Zinc Alloy Coated Steel. Our Woodgrain Series is a PVDF Pre-Painted Steel that is great for applications such as pre-engineered buildings, architectural wall panels, facades, and other applications where durability and long-lasting performance are required.
Printech products are manufactured using an offset gravure printing process. The offset gravure printing process utilizes cylinders that have digital patterns etched into the surface. The etched cylinder rotates in an ink bath and ink collects within the etched pattern, with the excess ink being scraped from the cylinder. The inked pattern is then transferred from the etched cylinder to a rubber-covered transfer roll. From there the inked pattern transfers to the steel substrate by passing between the transfer roll and an impression roll.
Specifictions of Printech steel sheet with wooden pattern PPGI
| Base Material | Galvanized, galvalume steel, Aluzinc, HDGI, CR, Aluminum |
| Grade | SGCC, DX51D, ASTM A653, EN10142, S350GD, etc. |
| Steel thickness | 0.17-1.5mm |
| Steel Width | within 1300mm |
| Zinc coating | 30-275gsm/m2 |
| Color | RAL color, wood, marble, stone, hairline, brick,camouflage series, etc. |
| Paint | PE, HDP, SMP, PVDF, FEVE |
| Coil ID | Ф508mm Ф610mm |
| Coil weight | 3-7 tons |
Quality Test
We can accept the third-party inspection before shipment like SGS, BV for PPGI, PPGL, GI, GL, Prepainted steel, color coated steel coils, printech wooden texture steel, wooden plain steel, brick, marble, stone, camouflage color steel and PVC laminated steel sheet.
Packing and Shipping
1) 4 eye bands and 4 circumferential bands in steel.
2) Printech wooden pattern PPGI fluted rings on inner and outer edges.
3) Wood texture steel metal & waterproof paper wall protection disk.
4) Wood plain color coated steel coil & waterproof paper around circumference.
Application cases
We foucs on the development and production of exterior wall wooden color steel sheet, 3D effects, made by 5 suits of printing technology.It has a strong sense of three-dimensional, high precision, simple construction,cost savings, nano-environmental technology, replace real marble effectively.
It is widely used of wooden design prepainted galvanized steel sheet in the external walls of the villa, thermal insulation wallboard,interior decoration etc.
Connection Information
Anna | Sales Manager
Mobile: 86-13853841010
Tel:86-635-2532001 Fax:86-635-2532666
Email:lyuda@lqhongji.com
Web:www.lqhongji.com
FAQ
1. Are you a trader or manufacturer?
We are a manufacturer, our factory located in jinan city , shandong province, China.
2. Can you provide the sample ?
Yes ,We can provide free sample for you to check the quality , but you need arrange the express cost.
3. What is your MOQ?
Normally the Mimium order quantity is 20000KGS. but it can be less if there is available material in stock.
4. Whats your payment terms?
Normally our payment terms is 30% advance payment , the balance against B/L copy or L/C at sight.
5. How about your production leading time?
Normally it can be finished within 20-25 days after receiving prepayment.
